How to Buy a Power Supply

The power supply unit (PSU) is one of the few items in an electrical device that will affect the performance and reliability of your entire system. It's often the most undervalued, under-appreciated component within any device, yet one of the first components to cause failure.


This article focuses on the factors to look for when purchasing a PSU for a personal computer, but it may be applied to any application needing a regulated PSU. When following this guide, take into account your own application, and appropriately weigh each factor.

Steps

  1. Determine the wattage you need.Use a PSU calculator web page or software to help determine your requirements. Even better is to find a review of a similar system that measures power consumption. As that consumption is measured at the wall, multiply by the review system's power supplies efficiency to get the output. (If you don't know, 0.82 will be close or slightly pessimistic.) Don't purchase a PSU just above your requirements unless you plan not to upgrade the system. Also, PSUs age, losing power over time. Purchase a PSU that will take you through your next few upgrades, over a multiple-year period.
  2. Research which connectors you need.Newer PSUs will often provide both a 24-pin ATX connector that doubles as a 20-pin connector. Higher-end models may only provide a 24-pin connector, and lower-end models may provide just a 20-pin connector. Typically, most Pentium 4 and Athlon 64 CPU-based motherboards (and earlier) will require a 20-pin ATX connector, while newer motherboards require a 24-pin ATX connector. Also, most PSUs will have both a 4-pin and 8-pin auxiliary 12V connector for motherboards, and only high-end PSUs will have one or more 6-pin PCI-E connectors for video cards.
  3. Look for PSUs with high-efficiency ratings.And, ones rated under load temperatures, not room temperatures. Anything 80% and above is good. At 83%, approximately 17% of the wattage is lost as heat. Therefore, a PSU that may be advertised as a 500W PSU, will actually be drawing almost 600W at the wall. Efficiency drops over time and during the life of the PSU. A year-old PSU is most likely not capable of producing the same amount of energy it once did when it was new.
  4. Determine the robustness of the PSU.How well does the PSU handle changes in current? Although not a guarantee, there's a strong correlation between weight and quality: bigger components (i.e., capacitors) equate to a more tolerant, reliable PSU. This is one downside to a 120mm fan: while it does provide quieter cooling, the components to be cooled must be more tightly packed. If you don't care about noise, an 80mm cooling fan in the traditional place on the rear of the PSU may offer better value.
  5. Check the number of rails.Just as your house's fuse box includes both a large main breaker and a smaller circuit breaker per circuit to ensure the smaller-branch circuit wires do not overheat, high-capacity PSUs divide their output into multiple "rails," each with a smaller current limit. The relevant safety standard requires a 20A limit, which is quite generous, given that the wires are smaller than those used in your house to carry 15A. (But there's the advantage that the wires aren't hidden in walls, so they're cooled better, and you'll smell it if something starts burning.) This, however, makes connecting the PSU more complex; in addition to not overloading it overall, you have to avoid overloading each rail, or it will shut down. A good power supply will make that easy by providing rails totalling much more than the total PSU rating. A cheaper alternative is to provide just enough rails to total the overall capacity, which makes it difficult to use all of a power supply's capacity. (This may be a clue that the PSU is incapable of delivering its full-rated capacity.) An even cheaper alternative, which has become quite popular, is to eliminate all of the safety circuitry and produce a "single-rail" power supply that can deliver all of its output on any wire. This is technically in violation of the ATX-power-supply specification but has not proved to be a safety problem in practice, and is preferred by many people. A single-rail design isn't itself a sign of a low-quality PSU.
  6. Get a modular PSU.It will help eliminate extra wires to get in the way of cooling. Ignore the that modular cables create more resistance due to corrosion of contacts. The additional resistance is negligible.
  7. Compare the amperage of each voltage.A PSU's wattage rating isn't conducive to determining amperage at any specific voltage. All PSUs will have a sticker with their rated amperage at each voltage level. This information should be provided when purchasing a PSU from an online vendor and visible on the unit's retail box. As mentioned above, modern computers are 12V-heavy loads. A 500W PSU may sound adequate, but if its 12V amperage is in the low 20s or less (12V times 25A is 300W), it may not be able to power a modern computer.

Community Q&A

Search
  • Question
    How do I know how much wattage is too much for my computer?
    Top Answerer
    You can never have too many watts, but if you want to save power and money, tally up the minimum wattage for all your installed components and round up. For example, if your sound card needs at least 100W, your GPU 150W, and other miscellaneous components need 100W combined, then you can settle down on 500W to cover the power requirement.
    Thanks!
  • Question
    Is the charger the same for all laptops?
    wikiHow Contributor
    Community Answer
    Not usually, no. Sometimes laptops of the same brand that are similar models will have compatible chargers, but for the most part they are all different.
    Thanks!
  • Question
    I want to buy a computer power supply. How can I be sure it's legit?
    wikiHow Contributor
    Community Answer
    Before making your purchase, use a power supply calculator to count the total volts, watts and amperage for a suitable PSU. Buy a well-known brand (Seasonic, Thermaltake, Silverstone, etc.) from a reputable dealer with favorable reviews.
    Thanks!
Unanswered Questions
  • Why humans have 2 eyeballs in front but not left and right?
  • Is a gigabyte 720 PSU good for my Geforce GTX 970 GPU?
  • How do I fix an atx power supply?
  • What does it mean to compare amperage of each voltage?
Ask a Question
200 characters left
Include your email address to get a message when this question is answered.
  • Some brands release top-quality models, some just release value-line models, and others shouldn't be releasing models at all! To make things worse, some generally high-quality brands cash in on their reputation by making a cheap (in all senses of the word) line. Here's a categorized list of brands by quality grouping according to performance and reliability based on reputable, cross-brand reviews listed in the External Links. Note thatnot all models within a single brand label are of the same quality, and these are averages for the entire model range of brands, not just specific models.
    Please note: these lists may not reflect your own personal experience.
    • Top Quality(based upon electrical capabilities): Seasonic, Zippy, Silverstone, Enermax, Antec, Acbel, Akasa, AMS, Channel Well, Corsair, Delta, Etasis, EVGA, Zalman.
    • Low Quality(based upon RMA rate and intended application of value-line computers): A-TOP, Aerocool, APEX, Apevia (Aspire), Asus, ATADC, Athena Power, ATRIX, Broadway, Casecom, Deer, Diablotek, Dynapower, EagleTech, Enhance, Enlight, E-Power, FOXCONN, Futurepower, I-Star, In-Win, JPAC, Just PC, Kingwin, Linkworld, Lite-On, Logisys, Masscool, MGE, MSI, NMEDIAPC, Norwood Micro, NorthQ, Powmax, Q-Tec, SFC, Sintek, Shuttle, Skyhawk, Spire, Star Micro, STARTECH, TTGI, Wintech, XION, YoungYear, Zebronics.
    • Disputed Brands(deemed to be of good quality, but needing referenced reviews or articles, or those with disputed quality, or varying quality of different models): ABS/Tagan, BFG Tech, Coolermaster, Coolmax, FSP, Hiper, HIPRO, Mushkin, OCZ, PC Power & Cooling, NZXT, Raidmax/Sigma, Rosewill, Scythe, Sunbeam/Tuniq, Topower, Ultra, XClio, XIGMATEK, Thermaltake.
  • Discount rating inflation. Computer power supplies are particularly tricky, because there's been a shift in the requirements since the 1990s. High-powered 3D video cards and motherboards with a 4-pin "P4" connector to supply processor power, use a great deal of +12V power, which was only a fraction of the output capacity of older power supplies. To ensure reliable performance, 3D graphics-card makers recommended oversized power supplies. For example, a 600W supply to ensure 300W of +12V. Cost-conscious manufacturers, in turn, produced power supplies labeled "600W" that could produce 300W of +12V, but not more than that, knowing their customers would never actually ask for more power. Modern power supplies are all "12V heavy" in this way, able to produce most of their total output in the form of 12V, but overoptimistic manufacturer ratings are still common among cheaper power supplies; PSUs that come with cases are particularly prone to this. Some PSU-calculation software will include a considerable "fudge factor" to allow for this mislabeling.
  • Look past bells-and-whistles, such as lighted fans, adjustable fan speeds, sleeved cables, and painted or polished enclosures. Although these are certainly desirable features, they don't make up for performance or reliability shortcomings.
  • Purchase a PSU tester (typically between and US) to confirm all of the voltage rails are working on your new PSU. Note that PSUs with 24-pin connectors no longer supply -5V.
  • Major labels such as Rosewill (a house brand), offer value, but at the cost of performance and reliability. Labels like this are a good choice for low-end builds with minimal power requirements, but they're often overrated for their wattage output and under-protected for ensured reliability.

Warnings

  • Check the warranty. Compare each manufacturer's guarantee, return policy, and customer-service history. There are some PSU manufacturers that release great products with horrible support, and vice versa.
  • PSU manufacturers and distributors have no obligation to any standard of rating wattage. Many 'value' PSUs may not actually output the wattages they claim under real-world conditions. It's possible for a 500W 'value' PSU to produce less power than a quality PSU sold at 350W. Thus, 'upgrading' a PSU but selecting a low-end model, may actually be a downgrade!
  • Never open a power supply, in spite of information on the internet advising otherwise. Such articles are intended for qualified power supply repair technicians only. A power supply contains capacitors that hold a charge even while a computer is turned off; this discharge can seriously injure the user.
  • High-volume, low-quality manufacturers often purchase designs from other companies for use in their own products. These 'carbon-copy' designs are often of low quality. In turn, they release their carbon-copy product with additional bells-and-whistles and a different company 'label' to entice customers. They may even charge a premium for the additional features. If you're serious about purchasing a reliable PSU, only buy one from a manufacturer that designs a majority of their units. Good examples are and .
  • Never test a power supply with a paperclip. This is very dangerous for both the supply and the user because the paperclip conducts electricity.
